Description
The ZonePad 1 is a stylish and intuitive wall-mounted controller designed to provide convenient remote control of an individual audio zone. Featuring touch-sensitive controls, a contemporary design, and easy access to everyday functions, it allows users to manage audio levels and source selection directly within the zone. The unit includes a local microphone input and a mono music input, making it ideal for hospitality, retail, education, and commercial environments. With simple configuration options and seamless integration with compatible Optimal Audio systems, the ZonePad 1 delivers flexible and user-friendly zone control.
More Information
Key Features
- Single-zone wall controller
- Remote control of an individual audio zone
- Contemporary design suitable for any décor
- Intuitive touch-sensitive control interface
- Easy configuration to match venue requirements
- Local microphone input for announcements
- Local mono music input
- Quick access to everyday audio functions
- Long-distance CAT5 connectivity
- Seamless integration with Optimal Audio systems
- Simple installation and operation
- Cost-effective zone control solution
Technical Specifications
- Type: Single Zone Wall Controller with Local Mic and Line Inputs
- Local Microphone Input: 1
- Phantom Power: 48V
- Mic Gain Range: +12dB to +55dB
- Mic Processing: Fixed High-Pass Filter @ 160Hz
- Local Music Input: 1 × Mono
- Maximum CAT5 Cable Distance: 500m
- Connection: RJ45
- Data Protocol: Optimal Audio Proprietary Protocol over CAT5
- Case Material: Zinc-Plated Steel and ABS
- Lens Material: Clear Acrylic
- Back Box Compatibility: 2-Gang UK/EURO 20mm Deep Back Box or 3-Gang US Back Box (using US ZonePad Adapter Plate)
- Dimensions: 146mm (W) × 86.2mm (H) × 39.3mm (D)
- Dimensions (Imperial): 5.75″ (W) × 3.39″ (H) × 1.55″ (D)
- Weight: 0.35kg (0.8 lbs)
