Description
The Martin Audio TORUS T1215 is a high-performance passive constant curvature array loudspeaker designed for applications requiring coverage distances between 15 and 30 metres. Bridging the gap between traditional point source systems and large line arrays, the T1215 delivers excellent speech intelligibility, high SPL performance, and controlled coverage in a compact and cost-effective format. Featuring Martin Audio’s innovative Dynamic Horn Flare™ technology, it offers adjustable horizontal dispersion options, making it ideal for live events, theatres, Houses of Worship, corporate venues, and installed sound applications.
Key Features
- Passive 2-way constant curvature array enclosure
- Fixed 15° vertical coverage pattern
- Dynamic Horn Flare™ technology
- Selectable 60°, 75° asymmetrical, or 90° horizontal dispersion
- High-output 12″ neodymium LF driver
- Triple HF compression driver configuration
- Peak SPL of 134dB
- Compact and installation-friendly design
- Optimized for medium-throw applications (15–30m)
- Compatible with Martin Audio iKON amplifier presets
Technical Specifications
- Type: Passive 2-way Constant Curvature Array Loudspeaker
- Frequency Response: 65Hz – 18kHz (±3dB), -10dB @ 50Hz
- LF Driver: 12″ (300mm) neodymium driver with 3″ voice coil
- HF Drivers: 3 × 1″ exit HT Polymer dome neodymium compression drivers with 1.4″ voice coils
- Sensitivity: 100dB (2.83V @ 1m free-field)
- Rated Power:
- 400W AES
- 1600W Peak
- Maximum SPL:
- 128dB Continuous
- 134dB Peak
- Nominal Impedance: 8 Ohms
- Dispersion:
- Horizontal: 60°, 75° Asymmetrical, or 90° selectable
- Vertical: 15°
- Input Connections: 1+/1- or 2+/2-
- Link Connections: 1+/1- and 2+/2-
- Enclosure Design: Constant Curvature Array
- Dimensions (W × H × D): 650 × 369 × 452 mm
- Dimensions (Imperial): 25.59 × 14.51 × 17.80 in
- Weight: 31 kg
