The VRX928LA is a lightweight (28 lb / 13 kg) compact 8″ two-way linearray speaker system designed for use in arrays of up to six units.
More Information
Features
Constant Curvature Array – The waveguide mounts two compression drivers on a continuous arc, enabling them to work together acoustically as if they were a single driver.
Amplitude Shading- A convenient series of switches on each enclosure that controls the output of each high-frequency section in the array.
Suspension and Rigging.
Dual Angle Pole Socket – JBL’s dual-angle pole sockets allow great flexibility in aiming the enclosure
(not on – WH version)
Differential Drive® Woofer.
Technical Specification
Tech Specs
Powered: No
LF Driver Size:8″
HF Driver Size:1″
Power Rating:800W
Total Power:1600W
Inputs:2 x Speakon
Impedance:8 ohms
Frequency Range:70Hz-20khz
Crossover Frequency:2kHz
Maximum Peak SPL:122dB
Horizontal Coverage Angle:100 Degrees
Vertical Coverage Angle:15 Degrees
Mounting Options: Pole Mount with dual 1.41″ socket, Fly Mount (optional hardware required)
