Description
The Martin Audio LE100 is an ultra-compact two-way passive stage monitor designed to deliver exceptional clarity, coverage consistency, and high output in a low-profile enclosure. Featuring Martin Audio’s advanced Coaxial Differential Dispersion™ technology, the LE100 provides uniform sound distribution across the listening area, ensuring performers receive clear and accurate monitoring wherever they are positioned on stage. Its compact design, versatile deployment options, and robust construction make it ideal for stage monitoring, portable PA systems, and fill applications.
More Information
Key Features
- Compact two-way passive stage monitor
- Coaxial Differential Dispersion™ technology
- Coaxial point-source performance for improved phase coherence
- Defined near-rectangular coverage plane at head height
- 12-inch long-excursion LF driver with low-distortion motor design
- 1-inch exit HF compression driver with polyimide dome diaphragm
- Low-profile enclosure design for unobtrusive stage placement
- Wide and consistent audience coverage
- Integral pole-mount socket with removable bung
- Multiple NL4 connectors for flexible deployment
- M8 rigging inserts for installation applications
- Durable plywood enclosure for touring and fixed installations
Technical Specifications
- Type: Two-Way Passive Coaxial Differential Dispersion Stage Monitor
- Frequency Response: 78Hz – 20kHz (±3dB), -10dB @ 58Hz
- LF Driver: 12″ (300mm) with 2.5″ (63.5mm) voice coil
- HF Driver: 1″ (25mm) exit, 1.7″ (44mm) voice coil polyimide dome compression driver
- Power Handling: 300W AES, 1200W Peak
- Sensitivity: 97dB
- Maximum SPL: 129dB Peak
- Nominal Impedance: 8 Ohms
- Dispersion: 110°–60° Horizontal × 60° Vertical
- Crossover Frequency: 1.6kHz Passive
- Enclosure Material: Birch/Poplar Plywood
- Finish: Black Textured Paint
- Grille: Black Perforated Steel with Scrim Cloth Backing
- Baffle Angle: 27°
- Connectors: 5 × NL4 Type
- Pin Connections: 1+ / 1-
- Handles: 2 Integrated Pocket Handles
- Mounting: Pole-Mount Socket and 4 × M8 Rigging Inserts
- Protective Features: Rubber Feet on Base and Sides
- Dimensions (W × H × D): 490 × 302 × 472 mm
- Dimensions Including Feet (W × H × D): 496 × 305 × 472 mm
- Weight: 18 kg
