Description
The JBL JRX225 is a portable dual 15-inch two-way speaker system designed for live music performance and music playback applications. With dual JBL low-frequency drivers, a powerful compression driver, Quasi 3-Way design, and rugged MDF cabinet construction, it delivers strong bass, clear mid-range performance, and reliable sound reinforcement for DJs, bands, live events, and professional PA systems.
More Information
Key Features
- Portable dual 15-inch two-way speaker system
- Designed for live music performance and music playback
- Dual JBL low-frequency drivers for powerful bass output
- 64 mm edgewound ribbon voice coil for better efficiency and power handling
- JBL 2414H-C 1-inch polymer diaphragm compression driver
- Quasi 3-Way design improves bass and mid-range clarity
- Progressive Transition high-frequency waveguide for smooth coverage
- Advanced crossover network for balanced frequency response
- SonicGuard protection for high-frequency driver safety
- Rugged 19 mm MDF enclosure for durability
- 18-gauge perforated steel grille protects internal components
- Non-resonant all-steel handles for easy transport
- Suitable for DJs, bands, live sound, music playback, and PA applications
Technical Specification
- Product Type: Two-Way Sound Reinforcement Loudspeaker
- Brand: JBL Professional
- Model: JRX225
- System Type: Dual 15-inch Two-Way Speaker System
- Power Rating: 500W / 2000W
- Frequency Range (-10 dB): 42 Hz – 18 kHz
- Frequency Response (±3 dB): 62 Hz – 13 kHz
- Sensitivity: 100 dB SPL, 1W / 1m
- Nominal Impedance: 4Ω
- Recommended Amplifier Power: 500W to 1000W into 4Ω
- Maximum SPL: 133 dB
- Nominal Dispersion: 90° x 50°
- Crossover Frequency: 2.2 kHz
- Low-Frequency Driver: JBL M115-8A x 2
- High-Frequency Driver: JBL 2414H-C 1-inch exit compression driver
- Waveguide: Progressive Transition Waveguide
- Design Type: Quasi 3-Way
- Enclosure Material: 19 mm MDF, Medium Density Fiberboard
- Grille: 18-gauge perforated steel grille
- Handles: Non-resonant all-steel handles
- Product Dimensions: 1092 x 464 x 426 mm
- Product Dimensions: 43 x 18.3 x 16.8 in
- Net Weight: 42.6 kg / 94 lbs
