This Dante-compatible unit features 16 analog inputs and 8 analog outputs, enabling flexible system configuration with Yamaha digital mixers and processors. The Rio1608-D3 is housed in a sleek, sturdy chassis and features a redundant power supply that ensures serious reliability, while the newly added headphone socket and output delay provide additional versatility.

More Information

Key Features

Key Features

• Dante-enabled professional I/O rack for digital mixing systems
• 16 high-quality analog microphone/line inputs
• 8 balanced analog outputs
• Supports remote head amp control from compatible Yamaha consoles
• Built-in headphone output for local monitoring and signal checking
• Output delay function for time alignment in system setups
• Phase control for improved system tuning and alignment
• Improved sound quality with lower noise and wider dynamic range
• Dual redundant power supply for high reliability in live/mission-critical use
• Integrated network control and Dante audio transport
• Compatible with Yamaha RIVAGE PM, DM7, CL, and QL series consoles
• Rack-mount design suitable for touring and fixed installations

Technical Information

• Analog I/O: 16 inputs / 8 outputs
• Dante: 10 receive / 16 transmit channels
• Comprehensive display and local control of gain, delay and other parameters.
• Dual power supply units are built in for high reliability.
• Onboard headphone socket
• Power consumption: 60 W
• Dimensions (WxHxD): 480 x 132 x 370 mm (18.9” x 5.2” x 14.6”)
• Net Weight: 9.4 kg (20.7 lb)
