Description
The Yamaha CXS18XLF / CXS18XLFW is a high-performance bass-reflex subwoofer engineered to deliver exceptional low-frequency reproduction for professional live sound and installed audio applications. Designed to perfectly complement Yamaha CZR full-range loudspeakers, the CXS18XLF offers deep, powerful bass with outstanding clarity and impressive output levels of up to 133 dB SPL.
Featuring an advanced 18-inch low-frequency driver with a 4-inch voice coil and 1000W program power handling, this subwoofer delivers tight, accurate, and impactful bass performance for concerts, houses of worship, theaters, clubs, and corporate events. Its lightweight yet rugged plywood enclosure with premium Polyurea coating ensures long-lasting durability while maintaining excellent portability.
Available in both black (CXS18XLF) and white (CXS18XLFW) finishes, the subwoofer also supports cardioid configurations when used with compatible processors or DSP-equipped amplifiers, enabling improved low-frequency directivity and reduced stage noise.
Key Features
- 18-inch high-performance low-frequency transducer
- Large 4-inch voice coil for enhanced power handling and reliability
- High power handling: 1000W Program Input
- Bass-reflex cabinet design for extended low-frequency response
- Maximum SPL of 133 dB for powerful bass reinforcement
- Optimized to pair with Yamaha CZR Series loudspeakers
- Cardioid mode capable with external processors or DSP-equipped amplifiers
- Lightweight, durable plywood enclosure
- Premium Polyurea coating for superior protection against wear and impact
- SpeakON NL4MP connectors (Parallel ×2, Output ×1)
- Dual-pole mounting socket
- Available in Black (CXS18XLF) and White (CXS18XLFW) finishes
- Compatible with optional protective cover (SPCVR-DXS18X)
- Optional wheel kit (SPW-1) for easy transport
Technical Specifications
- Model: CXS18XLF / CXS18XLFW
- Type: Bass-Reflex Subwoofer
- Power Handling (PGM): 1000W
- Maximum SPL: 133 dB
- Nominal Impedance: 8 Ω
- Cardioid Mode: Supported with compatible processors or DSP amplifiers
- Connectors: SpeakON NL4MP × 3 (Parallel × 2, Output × 1)
- Pole Mount: Dual-Pole Socket
- Cabinet Material: Premium Plywood
- Finish: Durable Polyurea Coating
- Color Options: Black / White
- Optional Accessories: SPCVR-DXS18X Speaker Cover, SPW-1 Wheel Kit
- Applications: Live Sound, Touring, Houses of Worship, Clubs, Theaters, Corporate Events, Fixed Installations
