CROWN MA 5000i

Description

The Crown Macro-Tech i Series offers amazing power, light weight and ease of use for touring sound applications. The series includes onboard analog signal processing and a built-in network connection.

More Information

– The Macro-Tech i Series continues the Macro-Tech legacy of unparalleled sonic accuracy and detail, putting sound quality above all else

– Patented, cutting-edge Class-I circuitry gets more power out of an amplifier with less waste

– Rugged construction ensures that all Macro-Techs are built to withstand years of abuse on the road

– Global Power Supply — designed to deliver maximum power no matter what country you work in

– Built-in load, line voltage, input and output monitoring

– Standard Ethernet networking via System Architect lets system operators monitor and control the amplifier from any location

Technical Specification

Frequency Response:

±0.25dB

Signal to Noise Ratio:

>112dBTHD: <0.1%

THD+Noise:

<0.1%, 20Hz to 20kHz

Intermodulation Distortion:

<0.35%

Damping Factor:

>5000

Crosstalk:

>80dB

Common Mode Rejection:

>70dB Typical

DC Output Offset:

<±3mV

Input Impedance:

20kΩ balanced, 10kΩ unbalanced

Maximum Input Level:

+20dBu

Typical Load Impedance:

Stereo: 1/2/4/8/16Ω; Bridge: 2/4/8Ω

Input Sensitivity:

1.4Vrms, 32dB gain, 26dB gain

Voltage Gain:

39.3dB to 24.5dB

Required AC Mains (±10%): Universal AC input, 100-240VAC, 50/60Hz

Dimensions:

19″ x 3.5″ x 16.2″ (48.3 cm x 8.9 cm x 41.1 cm)

Net Weight:

28 lbs (12.7 kgs)
